Overview
The V31 is an exceptional bi-directional RF link that combines video, telemetry data, and RF links into a single, integrated solution. Specifically designed to meet the needs of professional industrial users in applications such as UAVs and UGVs.
One of the standout features of the V31 is its impressive maximum range of 150km, allowing for long-distance communication in challenging environments.
The V31 supports both point-to-point and point-to-multipoint communication, unlocking a multitude of communication modes and possibilities, for example, one operator to multiple drones, or one drone to multiple receivers.
Product Introduction
VM31 is mesh radio developed based on LTE, OFDM, MIMO. With dual 10/100 Ethernet and serial gateway functions, it provides reliable wireless Ethernet bridge functions and gateway services for most devices. VM31 combines smooth integration with 3-in-1(video, telemetry, RC) link for a faster, more cost-effective path to system fielding. There are 3 frequencies for choice, 800MHz, 1.4GHz and 2.4GHz. Parameters are as below: It features compact size, high integration, high sensitivity, which provides great convenience for the user.
V31 Key Feature
- • Multi links in one module-Video & telemetry data & RC link
- • Light weight, compact size-175g
- • 2 frequencies for choice-800MHz and 1.4GHz
- • Dual SBUS input and output-Able to control the drone and the payload
- • LAN port for video input and output
- • Transparent data transmission-TTL, RS232 optional
- • Advanced technology-OFDM, MIMO
- • Adjustable RF power-2w and 5w
- • Adaptive mechanism-Self-adaptive data rate, bandwidth
- • Frequency hopping-Hop between frequency points
- • Latency-40ms from interface to interface
- • Encryption-AES128
- • Network mode-Point to point, point to multipoint, relay
- • Transmission range-5km, 20km, 30km, 50km, 80km
- • Network port expansion dock-Extend serial and LAN ports
- • Tracker antenna-Signal reception optimization
- • Video link workstation-Seamless connection between GCS and video link
Multi links in one module
Video & telemetry data & RC link
